High Efficiency Auto Rubber Car Parts Making Machine/Injection Molding Machine Spare Parts

Name: High Efficiency Auto Rubber Car Parts Making MachineInjection Molding Machine Spare Parts
Brand: JuChuan
Price: 16800 USD

Wholesale High Efficiency Auto Rubber Car Parts Making Machine/Injection Molding Machine Spare Parts from china suppliers

Place of Origin : Guangdong, China

Model Number : JC-VI-AO

Brand Name : JuChuan

Certification : CE ISO9001:2015

Packaging Details : Fixed with hard straps.

Supply Ability : 100 Set/Sets per Month

Price : $16800-40,000.00/sets >=1 sets

MOQ : 1set

Payment Terms : L/C, T/T, Western Union

Delivery Time : 45 days

Condition : New

Style : VERTICAL

Plasticizing Capacity(g/s) : 100

Mold Height(mm) : 100 - 250 mm

Ejector Number : 3

Ejector Stroke(mm) : 100 mm

Ejector Force(kN) : 1000 kN

Theoretical Shot Volume(cm³) : 100 cm³

Injection Rate (g/s) : 100 g/s

Machine Type : Hydraulic

Injection Weight (g) : 100 g

Screw Speed (rpm) : 100 - 200

Screw diameter (mm) : 30 mm

Screw L/D Ratio : 20

Distance between Tie Bars : 400

Weight (KG) : 8000

Type : Silicone/Rubber Injection Machine

Open Stroke(mm) : 200 mm

Power (kW) : 40 kW

Warranty : 1 Year

Key Selling Points : Competitive Price

Applicable Industries : Manufacturing Plant

Automatic : yes

After-sales Service Provided : Engineers available to service machinery overseas, Video technical support, Online support

Injection Rate : Adjustable

Injection Weight : 500~10000cc

Clamp Force(Ton) : 50~1000

Injection Volume(cc) : 500~10000

Injection Pressure(kgf/xm2) : 1800

Platen Size(mm) : 300*300~1200*1200

Plunge Stroke(mm) : 300~500

Heater Capacity(kw) : 8.4~42

After Warranty Service : Video technical support, Online support

Clamping Force (kN) : 2000kN

Port : Guangzhou

Contact Now

High Efficiency Auto Rubber Car Parts Making Machine/Injection Molding Machine Spare Parts

VI-AO Series Vertical "all-in-out" Silicone/Synthetic Rubber Injection Machine

Feature:

• Suitable for automotive and electronic rubber parts, high/cold temp precision rubber parts, especially NBR products

• All-in-out structure, sprueless injection without material loss controllable injecting material temperature

• Excellent for high precision molding part

• 5-10 times better accuracy than conventional injection machine the measuring precision of 1000cc injection volume is up to ±0.1 g

• Anti-collision Molding System prevent mold damage occurring from misalignment (Patented)

• Servo-Controlled system -Up to 40% energy saving

• Proportional backpressure controlling characteristic

Model	Unit	50VI-AO	100VI-AO	200VI-AO	300VI-AO	400VI-AO	600VI-AO	800VI-AO	1000VI-AO
Clamping Force	Ton	50	100	200	300	400	600	800	1000
Injection Capacity	cc	500	500	2000	3000	4000	6000	8000	10000
Injection pressure	kgf/cm²	1800	1800	1800	1800	1800	1800	1800	1800
Operation table size	mm	300*300	400*400	550*560	700*700	700*700	850*850	1000*1000	1200*1200
Min. Mold Thickness	mm	50	50	100	100	100	100	150	150
Plunger stroke	mm	300	350	400	400	400	500	500	500
Distance of Thermo-plate	mm	350~450	400~500	500~600	500~600	500~600	600~700	650~800	650~800
Distance of Tie bar	mm	400*140	515*230	640*310	820*395	820*395	970*500	1140*600	1340*800
Die sinking type	2RT-3RT-4RT-Upper Mold-Lower Mold
Max. Operating Pressure	Mpa	20	20	20	20	20	20	20	20
Motor Power	hp	7.5	10	15	15	15	20	20	25
Electric Heating Power	Kw	8.4	10	15.3	24	24	29.75	35	42
Total Power	Kw	16.9	20.5	30.3	39	39	48.75	54	64.5
Gross weight	Ton	5.5	6	7.5	9	10	14.2	17.5	21
Dimension *(LWH)*	mm	20001500 H2800	24001650 3200	26002000 4000	27502265 4200	27502265 4200	32002500 4350	L3450W2750 H4500	37503050 5000

High Efficiency Auto Rubber Car Parts Making Machine/Injection Molding Machine Spare Parts

Application

High Efficiency Auto Rubber Car Parts Making Machine/Injection Molding Machine Spare Parts

Product Features

High Efficiency Auto Rubber Car Parts Making Machine/Injection Molding Machine Spare Parts

High Efficiency Auto Rubber Car Parts Making Machine/Injection Molding Machine Spare Parts Images
